Emergency Lighting
- Slim line design – 11mm.
- Combination optics ensure 150º ultra wide light dispersion.
- 9 high output LEDs.
- 22 flash patterns.
- Can be synchronised.
- Covert applications, install without rubber gasket.
- Low current draw.
- Multi-voltage.
- Environmentally sealed – IP67.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 1A @ 12V, 0.5A @ 24V
- Flash Patterns: 22
- Lens: Polycarbonate
- Approvals: ECE R10
- Light Source: 9 x 1W LED
- Wire Length: 180mm
- IP Rating: IP67
-
Colours :
Catalogue Downloads
- New streamline minebar range featuring all premium products including:
– IONNIC 103 LED beacon.
– Nordic CANIS GO 410 worklamp.
– Brigade tonal and bbs-tek reverse alarms. - Designed and manufactured in Australia from high quality components.
- Models also available with forward facing turn signal LEDs.
- All minebars equipped with ADR approved IONNIC LED combination lamps – stop, tail, indicator & reverse lamps.
- Extruded aluminium bar providing greater strength and adaptability.
- Stepped edge allows for the use of Rhino-Rack® mounting kits.
- Multi-voltage.
- Voltage: 12-24V
- Length: 1500mm
- Beacon Type: IONNIC 103 LED
- Reverse Alarm: Brigade Tonal 97dB(A)
- Signal Lamp Type: IONNIC Slimline LED
- Base: Powder Coated Aluminium
- Harness: 4m
Catalogue Downloads
- New streamline minebar range featuring all premium products including:
– IONNIC 103 LED beacon.
– Nordic CANIS GO 410 worklamp.
– Brigade tonal and bbs-tek reverse alarms. - Designed and manufactured in Australia from high quality components.
- Models also available with forward facing turn signal LEDs.
- All minebars equipped with ADR approved IONNIC LED combination lamps – stop, tail, indicator & reverse lamps.
- Extruded aluminium bar providing greater strength and adaptability.
- Stepped edge allows for the use of Rhino-Rack® mounting kits.
- Multi-voltage.
- Voltage: 12-24V
- Length: 1275mm
- Beacon Type: IONNIC 103 LED
-
Worklamp: Nordic CANIS GO 410
Flood pattern -
Reverse Alarm: Brigade Tonal 97dB(A)
Brigade bbs-tek 92dB(A) - Signal Lamp Type: IONNIC Slimline LED
- Base: Powder Coated Aluminium
- Harness: 4m
Catalogue Downloads
- New streamline minebar range featuring all premium products including:
– IONNIC 103 LED beacon.
– Nordic CANIS GO 410 worklamp.
– Brigade tonal and bbs-tek reverse alarms. - Designed and manufactured in Australia from high quality components.
- Models also available with forward facing turn signal LEDs.
- All minebars equipped with ADR approved IONNIC LED combination lamps – stop, tail, indicator & reverse lamps.
- Extruded aluminium bar providing greater strength and adaptability.
- Stepped edge allows for the use of Rhino-Rack® mounting kits.
- Multi-voltage.
- Voltage: 12-24V
- Length: 1275mm
- Beacon Type: IONNIC 103 LED
-
Reverse Alarm: Brigade Tonal 97dB(A)
Brigade bbs-tek 92dB(A) - Signal Lamp Type: IONNIC Slimline LED
- Base: Powder Coated Aluminium
- Harness: 4m
Catalogue Downloads
The new IONNIC Minebar range is once again setting the standard for industrial design incorporating the highest quality components available.
The core range is now all LED and multi-voltage utilising components from industry leaders NORDIC LIGHTS and BRIGADE.
Our dedicated anodised aluminium extrusion provides a platform for a consistent high quality build that can be customised to specific site requirements and allows for range of universal and vehicle specific mounting options.
Manufactured here in Australia for local conditions.
- Voltage: 12-24V
- Material: Powder Coated Aluminium
- Harness: 4m
Catalogue Downloads
- SAE class 1 rated output.
- 11 flash patterns.
- Vibration resistance rated to SAE J575.
- New rugged base design with increased surface area providing improved heat dissipation.
- Polycarbonate lens for high durability.
- Low current draw.
- Multi-voltage.
- Environmentally sealed – IP67.
- Aerodynamic low profile.
- Magnetic version features cigar plug with integrated on/off & pattern select switches.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 3.2A @ 12V
- Flash Patterns: 11
- Lens: Polycarbonate
- Base: Aluminium
- Cord: 3.5m
- Plug: Cigar with switch
-
Approvals: ECE R10
ECE R65
SAE J845 Class1 - Ingress Protection: IP67
- Vibration: SAE J575
- Operating Temp: -30°C to 50°C
- Light Source: 18 x 3W LED
-
Colours :
Catalogue Downloads
- Can be used in 3 modes:
- Colour 1
- Colour 2
- Dual colour mode - 11 flash patterns in single colour mode, 5 flash patterns in dual colour mode.
- Vibration resistance rated to SAE J575 standard.
- Polycarbonate lens for high durability.
- Low current draw.
- Multi-voltage.
- Environmentally sealed – IP67.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 3.2A @ 12V
-
Flash Patterns: Single Colour Mode - 12
Dual Colour Mode - 5 - Lens: Polycarbonate
- Base: Die-cast Aluminium
- Approvals: ECE R10, ECE R65
- Vibration: SAE J575
- Wire Length: 700mm
- Ingress Protection: IP67
- Operating Temp: -30°C to 50°C
- Light Source: 18 x 3W LED
-
Colours :
Catalogue Downloads
- SAE class 1 rated output on selected models.
- 11 flash patterns.
- Vibration resistance rated to SAE J575.
- New rugged base design with increased surface area providing improved heat dissipation.
- Polycarbonate lens for high durability.
- Low current draw.
- 103 & 106 beacons can be synchronised.
- Multi-voltage.
- Environmentally sealed – IP67.
- Aerodynamic low profile.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 3.2A @ 12V
- Flash Patterns: 11
- Lens: Polycarbonate
- Base: Aluminium
-
Approvals: Amber & Blue
ECE R10, ECE R65
Amber
SAE J845 Class1 - Vibration: SAE J575
- Wire Length: 700mm
- Ingress Protection: IP67
- Operating Temp: -30°C to 50°C
- Light Source: 18 x 3W LED
-
Colours :
Catalogue Downloads
- 3W High Output LEDs.
- Slim line design – 11mm.
- Combination optics ensure 150º ultra wide light dispersion.
- 9 high output LEDs.
- 22 flash patterns.
- Can be synchronised.
- Covert applications, install without rubber gasket.
- Low current draw.
- Multi-voltage.
- Environmentally sealed – IP67.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 1.5A @ 12V, 0.75A @ 24V
- Flash Patterns: 22
- Lens: Polycarbonate
- Approvals: ECE R10
- Light Source: 9 x 3W LED
- Wire Length: 180mm
- IP Rating: IP67
-
Colours :
Catalogue Downloads
- 3W High Output LEDs.
- Slim line design – 11mm.
- Combination optics ensure 150º ultra wide light dispersion.
- 6 high output LEDs.
- 22 flash patterns.
- Can be synchronised.
- Covert applications, install without rubber gasket.
- Low current draw.
- Multi-voltage.
- Environmentally sealed – IP67.
- 5 year warranty.
- Voltage: 12-24V
- Current Draw: 1.3A @ 12V, 0.7A @ 24V
- Flash Patterns: 22
- Lens: Polycarbonate
- Approvals: ECE R10
- Light Source: 6 x 3W LED
- Wire Length: 180mm
- IP Rating: IP67
-
Colours :
