Worklamps
- Latest high output LED technology.
- LED position lights can be switched to white or amber.
- Supplied with side & rear stainless steel mounting brackets.
- Mounting channel runs entire length of bar allowing flexible mounting options.
- Impact resistant lens.
- Environmentally sealed aluminium body – IP68, IP69K.
- TDEUTSCH 4 pin connectors on fly lead.
- Multi-voltage.
- 3 year warranty.
- Theoretical Lumen Output: 8,820lm
- Operating Lumen Output: 6,332lm
- Voltage: 10-30V
- Power Consumption: Max. 95W
-
Input Current: High Beam
6.2A @ 13.8V
Position Light
0.5A @ 13.8V -
Connector: Deutsch 4 Pin
on 500mm Fly Lead - Mount: Dual Bolt M8
- Lens: Polycarbonate
- Body: Aluminium
- Weight: 1.5kg
-
Approvals: ECE R10
ECE R7
ECE R112 - IP Rating: IP67/IP69K
- Operating Temp: -20°C to 45°C
- Colour Temperature: 5700K
- Light Source: 21 x Osram 5W LEDs
Catalogue Downloads
- Ultra compact & lightweight.
- Next generation LED's providing even greater light output.
- Multi-voltage operation.
- Long life LED.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Whiter than daylight colour temperature.
- Deutsch DT connector encapsulated in body.
- 5 year warranty.
- Theoretical Lumen Output: 1,600lm
- Operating Lumen Output: 1,000lm
- Weight: 0.6 kg
- Voltage: 9-68V
- Input Current: 0.25A @ 48V
- Max Power Consumption: 13 Watts
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: Single Bolt M10
- Shock: 60 G
- Vibration: 8G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- IP Rating: IP68
- Salt Mist: ISO 9227
- EMC: ISO 13766, ISO 14982, ISO 7637-2
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5700K
- Light Source: 1 x Lumileds® Luxeon M LED
Catalogue Downloads
- Compact & low profile design.
- Available in up or down side light dispersion models.
- Multi-voltage operation.
- Long life LEDs.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Extreme shock resistance.
- Whiter than daylight colour temperature.
- Replaceable lens.
- Deutsch DT connector encapsulated in body.
- 5 year warranty.
- Ideal for mining, forestry, construction and material handling application.
- Can be mounted on sides of excavator boom.
- Theoretical Lumen Output: 4,100lm
- Operating Lumen Output: 2,600lm
- Voltage: 12-24V
- Input Current: 1.3A @ 24V
- Max Power Consumption: 32 Watts
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
-
Mount: 4 x M8 Bolt
User supplied - Shock: 60 G
- Vibration: 15.3G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 1.6 kg
- IP Rating: IP68
- Salt Mist: ISO 9227
- EMC: ISO 13766, ISO 14982, ISO 7637-2
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5700K
- Light Source: 6 x Cree® XML-2 LEDs
Catalogue Downloads
- Extremely bright illumination - 11,500lm.
- Heavy duty QUAKE anti-vibration mounting system.
- Extreme shock resistance.
- Multi-voltage operation.
- Long life LEDs.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Whiter than daylight colour temperature.
- Deutsch DT connector encapsulated in body.
- 5 year warranty.
- Theoretical Lumen Output: 11,500lm
- Operating Lumen Output: 7,200lm
- Voltage: 18-32V
- Input Current: 3.5A @ 24V
- Max Power Consumption: 85 Watts
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: M8 Bolt
- Shock: 60G
- Vibration: 15.3G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 2.9 kg
- IP Rating: IP68
- Salt Mist: ISO 9227
-
EMC: ISO 13766
ISO 14982
ISO 7637-2 - Operating Temp: -40°C to 85°C
- Colour Temperature: 5700K
- Light Source: 8 x Lumileds® Luxeon LEDs
Catalogue Downloads
- Multi-voltage operation.
- Long life LEDs.
- Low current draw.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Extreme shock resistance.
- Even light pattern without hotspots.
- Whiter than daylight colour temperature.
- Deutsch DT connector encapsulated in body.
- Available boxed and in blister packaging.
- 5 year warranty.
- Theoretical Lumen Output: 3200lm
- Operating Lumen Output: 2000lm
- Voltage: 12-24V
- Input Current: 1.7A @ 24V
- Max Power Consumption: 40W
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: Single Bolt M10
- Shock: 60 G
- Vibration: 8G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 0.9 kg
-
IP Rating: IP68
IP6K9K -
EMC: SO 13766
ISO 14982
ISO 7637-2
EN12895 - Salt Mist: ISO 9227 240H
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5700 K
- Light Source: 10 x Lumileds Luxeon Z ES
Catalogue Downloads
- Compact design.
- Multi-voltage operation.
- Long life LEDs.
- Low current draw.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Extreme shock resistance.
- Whiter than daylight colour temperature.
- Deutsch DT connector encapsulated in body.
- Available boxed and in blister packaging.
- 5 year warranty.
- Theoretical Lumen Output: 1900lm
- Operating Lumen Output: 1200lm
- Voltage: 12-24V
- Input Current: 0.8A @ 24V
- Max Power Consumption: 20W
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: Single Bolt M8
- Shock: 60 G
- Vibration: 8G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 0.5 kg
-
IP Rating: IP68
IP6K9K -
EMC: SO 13766
ISO 14982
ISO 7637-2
EN12895 - Salt Mist: ISO 9227 240H
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5700 K
- Light Source: 6 x Lumileds Luxeon Z ES
Catalogue Downloads
- High output LEDs.
- Low current draw.
- Multi-voltage operation.
- Easy installation.
- Slimline design.
- Polycarbonate construction.
- Frosted lens for diffused light.
- Ultra wide 180° light dispersion.
- Single & Dual mounting bracket available.
- 5 year warranty.
- Voltage: 10-30V
- Current Draw: 0.4A @ 12V
- Lens: Polycarbonate
- Base: Polycarbonate
- Cable Length: 250mm
- Light Source: LED
- Bracket: Powder Coated Aluminium
- Operating Temp: -20°C to 60°C
Catalogue Downloads
- Cost effective, high quality worklamps.
- Compact design.
- Multi-voltage.
- Long life LEDs.
- Low current draw.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Extreme shock resistance.
- Deutsch DT connector encapsulated in body.
- 5 year warranty.
- Theoretical Lumen Output: 2800lm
- Operating Lumen Output: 1200lm
- Voltage: 9-32V
- Input Current: 1.0A @ 24V
- Max Power Consumption: 28W
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: Single Bolt M8
- Shock: 60G
- Vibration: 8G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 0.6 kg
-
IP Rating: IP68
IP6K9K -
EMC: ISO 13766
ISO 14982
ISO 7637-2
EN12895 - Salt Mist: ISO 9227 240H
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5000 K
- Light Source: 6 x Nichia® NVSWE21AT
Catalogue Downloads
- Cost effective, high quality worklamps.
- Compact design.
- Multi-voltage.
- Long life LEDs.
- Low current draw.
- Over voltage, over temperature, spike & polarity protected.
- Environmentally sealed cast alloy body.
- Extreme shock resistance.
- Deutsch DT connector encapsulated in body.
- 5 year warranty.
- Theoretical Lumen Output: 1600lm
- Operating Lumen Output: 1000lm
- Voltage: 9-32V
- Input Current: 0.6A @ 24V
- Max Power Consumption: 16W
- Lifetime: 50,000 Hrs
- Connector: Deutsch DT Series 2 Pin
- Mount: Single Bolt M8
- Shock: 60G
- Vibration: 8G rms 24 - 2000 Hz
- Lens: PC
- Body: Aluminium
- Weight: 0.4 kg
-
IP Rating: IP68
IP6K9K -
EMC: ISO 13766
ISO 14982
ISO 7637-2
EN12895 - Salt Mist: ISO 9227 240H
- Operating Temp: -40°C to 85°C
- Colour Temperature: 5000 K
- Light Source: 6 x Nichia® NVSWE21AT
Catalogue Downloads
- Sleek and stylish design.
- Exceptional light output.
- Adjustable heavy duty mounting brackets – sides and rear.
- Low profile.
- 90 Watt.
- Even light pattern without hotspots.
- Impact resistant lens.
- Environmentally sealed – IP68.
- Multi-voltage.
- 3 year warranty.
- Weight: 1.4kg
- Operating Temp: -40°C to 60°C
- Colour Temperature: 6500K
-
Approvals: ECE R10
ECE R112 - Operating Lumen Output: 6,950lm
- Theoretical Lumen Output: 8,100lm
- Light Source: 18 x LG InNotek LEDs
- Lens: Polycarbonate
- Body: Aluminium
- Voltage: 12-30V
- IP Rating: IP68
- Max Power Consumption: 90W
- Mount: Dual Bolt M8
-
Connector: Deutsch 2 Pin
on Fly Lead - Input Current: 5.5A @ 13.8V
